Prysmian products distributor

Rondoflex Chain

Recommended for all chain systems (e.g. container cranes, stacking cranes, indoor cranes, material handling equipment, etc.). Especially suitable in applications where, due to the outdoor installation, long travel distances or high travel speed, high performances are expected from the cable (such as long lifetime, full reliability, resistance to abrasion, etc.).

All Temp

ALL-TEMP INDUSTRITE® Control Cable is designed and manufactured for use in continuous flexing, twisting, and other abusive physical applications where flame, abrasion, chemicals, moisture, impact, tearing, and temperature extremes are considerations. Applications include portable control, spring and motor driven reels, festoon systems, power tracks, cable tenders, cranes and hoists.

Suitable for use indoors and outdoors on magnet cranes, barges, milling machines, mining equipment, and oil rigs, and are suitable for installations in water including aerator ponds

ACEFLEX

Flexible multiconductor cable class 5 according to IEC 60228. PVC jacket and insulation. Rated for 500/600V. Operating temperature range from -25 to 70 °C.

Flexible cable
Flame retardant
Low halogen emission
Low water absorption
Resistant against oils, fats and chemical influences

RETENAX RVK

Flexible multiconductor cable class 5 according to IEC 60228. XLPE insulation, black PVC jacket, current rating 0.6/1KV. Operating temperature range from -25 to 90 °C.

Flexible cable
Flame retardant
Low halogen emission
Low water absorption
UV resistant
Cold resistant
Resistant against oils, fats and chemical influences

BLINDEX

Flexible multiconductor instrumentation and control cable class 5 according to UNE EN 60228. For signal transmission in applications requiring the elimination of electromagnetic fields generated by external agents like variable speed drives, electronic scales, etc.

PVC insulated
Copper mesh
Black PVC jacket
Operating temperature range from -10 to 70°C
Flexible cable
Flame retardant
Fire resistant
Low water absorption
UV resistant

DATA FLEX LIYCY

Screened flexible multiconductor cable class 5. Copper conductors are twisted together for data or analog or digital signal transmission for industrial plants, measurement instruments and control in areas with electrical noise

PVC insulation
Special gray extra-flexible PVC jacket
Nominal voltage 250V
Operating temperature range from -5 to 80°C
Cable flexible
Flame retardant
Fire resistant
Low water absorption

MONOPOLAR: AFUMEX PLUS

Flexible monopolar cable class 5 according to UNE EN 60228. Special halogen-free compound jacket Afumex TI Z1 (Polyolefin) Nominal voltage 450/750V. Operating temperature range from -40 to 70°C

Flexible cable
Flame retardant
Fire resistant
Halogen-free
Low water absorption
Cold resistant
Low smoke and reduced emission of toxic gas in the event of a fire

FLAT FLEX

Primarily designed for use with festoon systems for the conveyance of electrical power and control to cranes, hoists, or any other equipment which travels with a lateral traversing motion.

Flat-FLEX can also be used where space is at a premium, since it can be stacked; or where extreme flexing is a requirement, recommended bend radius of three to five times cable diameter.

Flexible Cables

Rondoflex Chain

All Temp

Control Cables

ACEFLEX

Flexible multiconductor cable class 5 according to IEC 60228. PVC jacket and insulation. Rated for 500/600V. Operating temperature range from -25 to 70 °C.

Flexible cable
Flame retardant
Low halogen emission
Low water absorption
Resistant against oils, fats and chemical influences

RETENAX RVK

Flexible multiconductor cable class 5 according to IEC 60228. XLPE insulation, black PVC jacket, current rating 0.6/1KV. Operating temperature range from -25 to 90 °C.

Flexible cable
Flame retardant
Low halogen emission
Low water absorption
UV resistant
Cold resistant
Resistant against oils, fats and chemical influences

Shielded Control Cables

BLINDEX

PVC insulated
Copper mesh
Black PVC jacket
Operating temperature range from -10 to 70°C
Flexible cable
Flame retardant
Fire resistant
Low water absorption
UV resistant

DATA FLEX LIYCY

PVC insulation
Special gray extra-flexible PVC jacket
Nominal voltage 250V
Operating temperature range from -5 to 80°C
Cable flexible
Flame retardant
Fire resistant
Low water absorption

Halogen-Free Cables

MONOPOLAR: AFUMEX PLUS

Flexible monopolar cable class 5 according to UNE EN 60228. Special halogen-free compound jacket Afumex TI Z1 (Polyolefin) Nominal voltage 450/750V. Operating temperature range from -40 to 70°C

Flexible cable
Flame retardant
Fire resistant
Halogen-free
Low water absorption
Cold resistant
Low smoke and reduced emission of toxic gas in the event of a fire

Flat Cable

FLAT FLEX

Primarily designed for use with festoon systems for the conveyance of electrical power and control to cranes, hoists, or any other equipment which travels with a lateral traversing motion.

Flat-FLEX can also be used where space is at a premium, since it can be stacked; or where extreme flexing is a requirement, recommended bend radius of three to five times cable diameter.

There are many companies offering solutions in power cables. At Risoul, we have more than 40 years of experience in the electrical market and we have had the opportunity to get to know many of these brands. Based on our experience, we are a proud Prysmian distributor.

In Prysmian, we have found a manufacturer capable of developing solutions that not only meet the industry norms, but also satisfy the individual client’s needs. Prysmian is quick and efficient throughout the supply chain.

One of the strengths we value most in Prysmian is their constant investment in innovation and continuous improvement that has made this company a leader in service quality, speed and flexibility.

Prysmian seeks to be a facilitator, collaborating with customers for economic and social development in the countries where this group has a presence. With a strategy focused on growth and innovation, Prysmian plays a key role promoting improvements throughout the industry in high quality product development.
